DH208-X

Vertical Axis Engine Series

🔹 DH208-X – Compact Utility Engine

The DH208-X is a compact and efficient vertical axis engine designed for light to medium-duty applications. It delivers stable power output with low fuel consumption, making it suitable for portable equipment and small machinery.

📊 Technical Specifications

• Engine Model: DH208

• Displacement: 208 cc

• Net Power: 5.1 kW @ 3600 rpm

• Total Power: 7 HP @ 3600 rpm

• Torque: 13 Nm @ 2500 rpm

• Bore × Stroke: 70 × 54 mm

• Fuel Tank Capacity: 3.6 L

• Oil Capacity: 0.6 L

• Dry Weight: 14.7–16.7 kg

• Dimensions (L×W×H): 370 × 315 × 340 mm

⚙️ Key Features

• Easy start system with low-resistance decompression design and automatic choke

• Low vibration structure with optimized balance and low center of gravity

• Durable engine design using finite element analysis and independent mold development

• High-efficiency piston ring system for improved fuel economy and reduced oil consumption

• Reliable and stable operation under continuous load

• Compact and lightweight design for easy installation and portability

🏭 Application Areas

Suitable for a wide range of light-duty equipment, including:

• Construction machinery (light equipment)

• Garden tools and landscaping machines

• Water pumps and washing machines

• Small generators

• General-purpose industrial equipment

⭐ Core Advantages

• Compact and lightweight structure

• Fuel-efficient design

• Smooth and stable operation

• Easy starting system

• Wide application versatility
